The Marshall DSL100HR is a powerhouse 100 W tube guitar amplifier head with switchable output (also 50 W mode). It offers dual channels—Classic and Ultra gain—with two master volumes, Tone Shift, Resonance, Presence, digital reverb, and an effects loop. Equipped with Softube cabinet-emulated headphone/line out and five speaker jacks, it brings pro-grade flexibility for stage, studio, and home use.
SPECIFICATIONS:
Feature | Description |
---|---|
Model | DSL100HR (Head) |
Power Output | 100 W (tube) with switchable 50 W mode |
Channels | 2: Classic Gain (Clean/Crunch), Ultra Gain (Lead 1/Lead 2) |
Tubes (Preamp) | 4× ECC83 (12AX7) |
Tubes (Power amp) | 4× EL34 |
EQ & Tone Controls | Bass, Middle, Treble, Presence, Resonance, Tone Shift switch |
Effects | Built-in digital reverb (per channel), series FX loop |
Outputs | 5× ¼″ speaker jacks (4/8/16 Ω), ¼″ emulated line/headphone out |
Inputs | ¼″ guitar in, 3.5 mm aux in, MIDI in, footswitch input |
Power Reduction | Front & rear panel selectable for lower-watt operation |
Emulated Output | Softube 1960 cab-quality emulation |
Construction | Robust valve head with IEC power connector; weight 24.2 kg |
Dimensions | 740 × 274 × 242 mm |
